PowerWalker VFI 1000 TGS UK

Art-No: 10122104
EAN: 4260074979398

  • High efficiency results in energy saving with output power factor 0.9
  • Human Interface Device (HID) compatible USB connection (no additional drivers needed)
  • Wide input voltage range for all environments and support for AC generator
  • Available with stronger charger for external batteries
The PowerWalker VFI TG/TGB/TGS is a professional and versatile online UPS solution for almost all single-phase applications.
The UPS is available in different versions:
TG: with internal batteries for regular backup times
TGB: with internal batteries and connection for external battery packs for extended autonomy times
TGS: without internal batteries, but with a powerful charger for very long autonomy times

Thanks to the double converter technology, the UPS offers the best protection for sensitive systems. Additionally, the functionality is enhanced by the variety of communication options, such as HID, software or network cards.


Características Gerais
TypeOnline
Capacidade1000VA / 900W
Saída Fator de Potência0.90
Input
Intervalo de tensão de entrada176-300 VAC or 80x285 VAC in bypass mode
Max THDi≤5%
Input PF≥ 0.99 at full load
Faixa de Freqüência40Hz - 70Hz
Frequency (Synchronized Range)45Hz - 55Hz or 54Hz - 66Hz
Output
Tensão nominal de saída220/230/240 VAC
Onda sinusoidal puraYes
THDv≤2% Full Linear Load; ≤5% Non-Linear Load
Regulação de tensão (Bat. Mod.)±2%
Frequency (Battery Mode)±0,05Hz
Detalhes Técnicos
Load Crest Ratio3:1
Transfer Time [AC to Battery]0ms
Transfer Time [Inverter to Bypass]4ms
Generator supportYes
Overload CapacityLine: constant @100%-105%; 1min @105%-130%; 10s @130%-150%; 300ms @>150%; bypass at higher; BAT: 10s @100%-150%; cut-off at higher
External Battery ConnectionYes
Charger3A / 6A
Fan LogicAlways ON;
Low speed: bypass/ECO or line mode with load below 70%
High speed: Battery mode or line mode with load above 70%
Eficiência
LINE mode full Load89.0%
Baterias e tempo de autonomia
BatteriesDesigned to work with external batteries. Batteries are not included
DC Voltage2 x 12V
Ligações e comunicação
IEC C13 Outlet3
InputC14-UK
SoftwareWinPower
USB portYes
HID SupportYes
RS-232 PortYes
Extension SlotYes, 1
EPO PortYes
Ambiente
Nível de Ruído< 45dB
Temperatura0°C – 40°C
Humidade0% - 95% RH (non-condensing)
Logística
IEC 62040-3 classificationVFI-SS-311
Package ContentUPS, Manual, USB Cable, Input Power Cable, 2x IEC Cable
Manual LanguagesEN/DE/PL
EAN4260074979398
Largura102 mm
Altura229 mm
Profundidade346 mm
Peso3.8 kg
Giftbox - Largura194 mm
Giftbox - Altura330 mm
Giftbox - Profundidade423 mm
Giftbox - Peso4.5 kg
Pcs. per box1
Pcs. per pal42
