| Nome | Descrição do produto | Quadro |
AS400 Card
Item Number: 10120515
EAN: 4260074974300 | AS/400 Cards provide clean dry contacts for remote shutdown and monitoring of a UPS. It is frequently used along with PLCs and signal control panels. Information delivered are UPS failure, Alarm, Main Fail, Bypass, Battery Low, UPS On. Using AS/400 it possible to shutdown UPS remotely. Solution requires external 12V/24VDC source for a high signal.
Dimensions are 85 x 52 x 26 mm 35g
Pin assig ... |  |
ATS
Item Number: 10120543
EAN: 4260074974959 | PowerWalker ATS (Automatic Transfer Switch) also known as STS (Static Transfer Switch) is designed with two independent power inlets to supply power to the load from primary power source. Should primary power source fail, the secondary will automatically backup the connected equipment without any interruption. The transfer time from one to another is seamless to the connected equipment. After swit ... |  |
BP A48R-8x9Ah
Item Number: 10134014
EAN: 4260074977837 | BP uses empty housing number 10135001
Battery Pack for VFI 2000 CRM LCD (8x9Ah, 48VDC). Includes 2 strings of 4 batteries, each 12V/9Ah capacity. Battery pack operates on 48VDC nominal voltage. Dimensions are H:88mm x W:438mm x D:510mm. Weight: 29kg. ... |  |
EMD for SNMP Manager
Item Number: 10120544
EAN: 4260074974966 | EMD (environmental monitoring device) for SNMP Manager is a connectivity devices for remote monitoring of temperature and humidity. It provides dry contacts to communicate with compatible devices such as security system or alarm system. ... |  |
MBS/PDU Tower 1-3kVA
Item Number: 10120500
EAN: 4260074973082 | An external Maintenance Bypass Switch with function of a PDU (Power Distribution Unit). It provides continuous power without shutting down the connected loads during UPS scheduled maintenance or battery replacement. As a PDU it allows to distribute the power among several loads. It is rated up to 3000VA. ... |  |
MBS/PDU 19in 1-3kVA IEC
Item Number: 10120501
EAN: 4260074974195 | An external Maintenance Bypass Switch with function of a PDU (Power Distribution Unit). It provides continuous power without shutting down the connected loads during UPS scheduled maintenance or battery replacement. As a PDU it allows to distribute the power among several loads. It is rated up to 3000VA. ... |  |
Modbus Card 2
Item Number: 10120565
EAN: 4260074975703 | The PowerWalker Modbus Card is a communication accessory that provides a pair of RJ-45 interface for remote monitoring and controlling of UPSs. It converts standard RS232 signal to RS232 signal with specified address, which allows controlling many UPSs from one computer. You can setup a desired address with jumpers (range 0-255).
Modbus Card for: VFI LCD, VFI CG, VFI C, VFI RM, VFI RMG, VFI CRM ... |  |
Charger EB48-15A
Item Number: 10136002
EAN: 4260074978056 | External charger in a stand-alone housing. Works parallel to the UPS. You can connect your battery pack via connector (48VDC). Charger has adjustable current up to 15A. ... |  |
MBS/PDU IEC 1-3kVA
Item Number: 10133000
EAN: 4260074978025 | An external Maintenance Bypass Switch with function of a PDU (Power Distribution Unit). It provides continuous power without shutting down the connected loads during UPS scheduled maintenance or battery replacement. As a PDU it allows to distribute the power among several loads. It is rated up to 3000VA. ... |  |
Rack Mount Kit - RK3
Item Number: 10120507
EAN: 4260074974218 | The rack-mount kit can be extended to 740mm. This enables to install the rack- mount kit into server cabinets with already locked support frames. This kit is also suitable for server cabinet up to 1200mm depth with middle support frame.
- Extendable from 470mm up to 740mm
- Suitable for VFI 1000-3000 RM, VFI 1000-3000 RMG, VFI 1000-3000 CRM, VFI 1000-3000 CRS, VFI 1000 R/1U
- Dimensio ... |  |
SNMP Manager
Item Number: 10120505
EAN: 4260074974034 | SNMP Cards offer IP Address and Web Interface for most convenient monitoring. SNMP modules allows remote monitor and manage multiple UPSs from anywhere with internet access. Integrated web access will leverage internet capability of SNMP card to remotely program or shut down UPSs. Equipped with SNMP card, power conditions of all UPSs can be monitored anytime/anywhere even through the UPS units are ... |  |
SNMP Box
Item Number: 10131000
EAN: 4260074977424 | PowerWalker SNMP Box is a communication solution for multiple UPS monitoring and control. Integrated web access will leverage internet capability of SNMP to remotely program or shut down UPSs. Equipped with SNMP Box, power conditions of all UPSs can be monitored anytime/anywhere even though the UPS units are located in different floors. Besides, this module also come equipped with easy-to-update f ... |  |
USB Cable
Item Number: 91010011 | Additional communication cable ... | .jpg&w=150&h=350) |
RS-232 Cable
Item Number: 91010012 | Additional communication cable ... | .jpg&w=150&h=350) |
IEC Cable 10A C13/C14 (180cm) 0.75mm²
Item Number: 91010013
EAN: 4260074976274 | Additional power cable ... | .jpg&w=150&h=350) |
EU Input Power Cable C13
Item Number: 91010017
EAN: 4260074976465 | Additional power cable ... | .jpg&w=150&h=350) |
EU Input Power Cable C19
Item Number: 91010018
EAN: 4260074976458 | Additional power cable ... | .jpg&w=150&h=350) |
IEC Cable 16A C19/C20 (180cm)
Item Number: 91010028
EAN: 4260074976090 | Additional power cable ... | .jpg&w=150&h=350) |
UK Input Power Cable C13 (180cm)
Item Number: 91010029
EAN: 4260074975826 | Additional power cable ... | .jpg&w=150&h=350) |
UK Input Power Cable C19 (180cm)
Item Number: 91010030
EAN: 4260074975833 | Additional power cable ... | .jpg&w=150&h=350) |
IEC Cable 10A C14/C19 (180cm)
Item Number: 91010040
EAN: 4260074976182 | Additional power cable ... | .jpg&w=150&h=350) |
IEC Cable 10A C13/C20 (180cm)
Item Number: 91010041
EAN: 4260074975710 | Additional power cable ... | .jpg&w=150&h=350) |
IEC Cable 10A C14/TypeF Converter (20cm)
Item Number: 91015003
EAN: 7340004644842 | ... | .jpg&w=150&h=350) |
