Descrição do produto

PowerWalker VI 3000 RT HID

Art-No: 10120024
EAN: 4260074974171

Rack/Tower design with swappable LCD direction
Pure Sinewave Output with Power Factor 0.9
Selectable line sensitivity allowing generator support
USB with Human Interface Device (HID) support and Intelligent Slot for communication cards

The PowerWalker VI RT HID is a robust Line-Interactive UPS with pure sine wave output and Human Interface Device (HID) support. It was designed to fulfill the high power quality demand in IT-environment while still keeping the line-interactive topology. The VI RT HID offers full protection for devices such as servers, network/telephone communication systems and small industrial applications.
Due to its 2U design and adjustable LCD display, the UPS can be installed inside any regular 19” rack cabinet or used as tower system.

IEC

Características Gerais
Type	Line-Interactive
Capacidade	3000VA / 2700W
Saída Fator de Potência	0.90
Input
Intervalo de tensão de entrada	Acceptable Voltage Range 0-300VAC Line Low Transfer (Wide Mode) 154/161/168VAC ± 4% Line Low Transfer 176/184/192VAC ± 4% Line Low Comeback 186/194/202VAC ± 4% Line High Transfer 264/276/288VAC ± 4% Line High Comeback 254/266/278VAC ± 4%
Faixa de Freqüência	45Hz - 65Hz (self-adaptive to 50/60Hz); 40Hz - 65Hz for generator mode
Frequency (Synchronized Range)	50Hz or 60Hz
Output
Tensão nominal de saída	220/230/240 VAC
Onda sinusoidal pura	Yes
Regulação de tensão (Bat. Mod.)	±5%
Frequency (Battery Mode)	±0,1Hz
Detalhes Técnicos
Surge protection	430/250 Joule (LV/HV)
Transfer Time [AC to Battery]	2-6ms typical; 10ms maximal; 13ms for generator mode
Generator support	Yes
Overload Capacity	Line: 3min @100%-120%; 0.2s @140%-160%; BAT: 30s @100%-115%; 0.1s @115%-130%
External Battery Connection	Yes
Charger	1.5A
Fan Logic	Fan Off: Line/Standby Mode (no AVR) with full battery in float mode with load below 80%: Fan Off Line/Standby Mode (no AVR) with load above 80%: Half Speed Line/Standby Mode (no AVR) charging batteries: Half Speed Battery Mode with load above 50%: Full Speed Battery Mode with load below 40%: Half Speed Other Mode with temperature above 45degC: Full Speed Other Mode with temper
LCD Indicators	UPS status, Load level, Battery level, Input/Output voltage, AC mode, battery mode, Bypass mode, fault conditions Display colour: Blue, red, red flashing (depends on UPS status)
Eficiência
LINE mode full Load	98.5%
Energy Star compliance	Yes
Baterias e tempo de autonomia
Batteries	6x 12V/9Ah
DC Voltage	6 x 12V
Recharge Time	4h to 90%
Full Load Backup Time	3min
Half Load Backup Time	7min
Ligações e comunicação
IEC C13 Outlet	8
IEC C19 Outlet	1
Programmable Outlets	Yes
Input	C20
Software	WinPower
USB port	Yes
HID Support	Yes
RS-232 Port	Yes
Extension Slot	Yes, 1
Dry Contacts	Yes
EPO Port	Yes
RJ-45/RJ-11 protection	Yes
Ambiente
Nível de Ruído	< 45dB
Temperatura	0°C – 40°C
Humidade	20% - 80% RH (non-condensing)
Logística
IEC 62040-3 classification	VI-SS-311
Package Content	UPS, Manual, USB Cable, Input Power Cable, RS-232 Cable, 2x IEC Cable, Tower holder, Rack Ears, EPO Plug
Manual Languages	EN/DE/RU/PL/CZ/FR/HU
EAN	4260074974171
Largura	438 mm
Altura	86.5 mm
Profundidade	608 mm
Peso	30.42 kg
Giftbox - Largura	790 mm
Giftbox - Altura	236 mm
Giftbox - Profundidade	590 mm
Giftbox - Peso	34.4 kg
Pcs. per box	1
Pcs. per layer	2
Pcs. per pal	16

Nome	Descrição do produto	Quadro
ATS Item Number: 10120543 EAN: 4260074974959	PowerWalker ATS (Automatic Transfer Switch) also known as STS (Static Transfer Switch) is designed with two independent power inlets to supply power to the load from primary power source. Should primary power source fail, the secondary will automatically backup the connected equipment without any interruption. The transfer time from one to another is seamless to the connected equipment. After swit ...
BP P72R-12x9Ah Item Number: 10134012 EAN: 4260074977554	BP uses empty housing number 10134019 Battery Pack for VI/VFI 3000 RT (12x9Ah, 72VDC). Includes 2 strings of 6 batteries, each 12V/9Ah capacity. Battery pack operates on 72VDC nominal voltage. Dimensions are H:86,5mm x W:438mm x D:608mm. Weight: 44,5kg. ...
EMD for NMC Card Item Number: 10120545 EAN: 4260074974973	EMD (environmental monitoring device) for NMC Card is a connectivity devices for remote monitoring of temperature and humidity. It provides dry contacts to communicate with compatible devices such as security system or alarm system. ...
Rack Mount Kit - RK1 Item Number: 10120529 EAN: 4260074974584	The rack-mount kit can be extended to 740mm. This enables to install the rack- mount kit into server cabinets with already locked support frames. This kit is also suitable for server cabinet up to 1200mm depth with middle support frame. - Extendable from 460mm up to 740mm - Suitable for VI RT, VI RT LE, VFI RT Series - Dimensions: 430 x 57 x 44.5 mm, 2kg ...
AS400 Card 2 Item Number: 10120527 EAN: 4260074974560	AS/400 Cards provide clean dry contacts for remote shutdown and monitoring of a UPS. It is frequently used along with PLCs and signal control panels. Information delivered are UPS failure, Alarm, Main Fail, Bypass, Battery Low, UPS On. Using AS/400 it possible to shutdown UPS remotely. Solution requires external 12V/24VDC source for a high signal with max 1A. Dimensions are 130 x 61 x 1.6 mm 50 ...
MBS/PDU Tower 1-3kVA Item Number: 10120500 EAN: 4260074973082	An external Maintenance Bypass Switch with function of a PDU (Power Distribution Unit). It provides continuous power without shutting down the connected loads during UPS scheduled maintenance or battery replacement. As a PDU it allows to distribute the power among several loads. It is rated up to 3000VA. ...
MBS/PDU 19in 1-3kVA IEC Item Number: 10120501 EAN: 4260074974195	An external Maintenance Bypass Switch with function of a PDU (Power Distribution Unit). It provides continuous power without shutting down the connected loads during UPS scheduled maintenance or battery replacement. As a PDU it allows to distribute the power among several loads. It is rated up to 3000VA. ...
MBS/PDU IEC 1-3kVA Item Number: 10133000 EAN: 4260074978025	An external Maintenance Bypass Switch with function of a PDU (Power Distribution Unit). It provides continuous power without shutting down the connected loads during UPS scheduled maintenance or battery replacement. As a PDU it allows to distribute the power among several loads. It is rated up to 3000VA. ...
NMC Card Item Number: 10120517 EAN: 4260074974461	SNMP Cards offer IP Address and Web Interface for most convenient monitoring. SNMP modules allows remote monitor and manage multiple UPSs from anywhere with internet access. Integrated web access will leverage internet capability of SNMP card to remotely program or shut down UPSs. Equipped with SNMP card, power conditions of all UPSs can be monitored anytime/anywhere even through the UPS units are ...
Battery Set for VI/VFI 3000RT LCD (for main unit) Item Number: 91010054 EAN: 4260074977639	...
Battery Set for VI/VFI 3000RT LCD (for main unit) Item Number: 91010054 EAN: 4260074977639	...
PWB12-7 Item Number: 91010090 EAN: 4260074978131	7Ah general purpose battery. PowerWalker PWB12 battery series is designed to work with UPS solutions. It is a high quality valve-regulated lead acid battery with high corrosion resistance and special exhaust structure. The sealing technology with high discharge capacity offers long life, reliability and safety. Batteries are flexible for installation and maintenance and easy to handle. < ...
PWB12-9 Item Number: 91010091 EAN: 4260074978148	9Ah general purpose battery. PowerWalker PWB12 battery series is designed to work with UPS solutions. It is a high quality valve-regulated lead acid battery with high corrosion resistance and special exhaust structure. The sealing technology with high discharge capacity offers long life, reliability and safety. Batteries are flexible for installation and maintenance and easy to handle. < ...
USB Cable Item Number: 91010011	Additional communication cable ...
RS-232 Cable Item Number: 91010012	Additional communication cable ...
IEC Cable 10A C13/C14 (180cm) 0.75mm² Item Number: 91010013 EAN: 4260074976274	Additional power cable ...
EU Input Power Cable C13 Item Number: 91010017 EAN: 4260074976465	Additional power cable ...
EU Input Power Cable C19 Item Number: 91010018 EAN: 4260074976458	Additional power cable ...
IEC Cable 16A C19/C20 (180cm) Item Number: 91010028 EAN: 4260074976090	Additional power cable ...
UK Input Power Cable C13 (180cm) Item Number: 91010029 EAN: 4260074975826	Additional power cable ...
UK Input Power Cable C19 (180cm) Item Number: 91010030 EAN: 4260074975833	Additional power cable ...
IEC Cable 10A C14/C19 (180cm) Item Number: 91010040 EAN: 4260074976182	Additional power cable ...
IEC Cable 10A C13/C20 (180cm) Item Number: 91010041 EAN: 4260074975710	Additional power cable ...
IEC Cable 10A C14/TypeF Converter (20cm) Item Number: 91015003 EAN: 7340004644842	...

	Folha de dados
	Common Manual - Portugal
	Common Manual [DE] [DK] [EN] [ES] [FI] [FR] [IT] [NL] [NO] [PL] [PT] [RO] [RU] [SE] [SI]
	PowerWalker VI RT HID - Quick Guide - Portugal
	PowerWalker VI RT HID - Quick Guide [DE] [EN] [ES] [FR] [IT] [PL] [PT] [RU]
	PowerWalker VI+VFI RT HID - Assembly - Portugal
	PowerWalker VI+VFI RT HID - Assembly [DE] [EN] [ES] [FR] [IT] [PL] [PT] [RU] [DE] [EN] [ES] [FR] [IT] [PL] [PT] [RU]
